Overall plate structure, the box materials using standard 304 stainless steel, double waterproof treatment.Can be installed in indoor, outdoor with shed, applicable to restrict the passing rate of the place, has the count, attendance, current limiting function
Technical Parameters :
| Model | UT560-B |
| Brand | UNIQSCAN |
| Dimension | 1200*300*980 mm |
| Arm length | 500mm(norm) |
| Material | 304 # stainless steel |
| Tickness | Head: 1.5mm , Cabinet:1.2mm |
| Input Voltage | AC220±10%,50HZ |
| Driving motor | 24V |
| Failure-free operation | 5 million/time |
| Weight | 35kg |
| Traffic speed | 35 persons/min |
| Flap Opening/Closing Time | 0.2s |
| Channel width | ≤600mm |
| Infrared sensor | 3 pairs |
| Operating temperature | -30ºC-70ºC |
| Communication interface | RS485/TCP/IP |
| Working environment | indoor and outdoor |
Scope:
Access control system: Combine with rfid/fingerprint/veins/facial readers, apply to factory, school, dormitory, residential, construction site.
Ticketing system: Combine with rfid/QR code/barcode readers, apply to public park, tourism area, subway, bus station, air port, dock, play ground, gym, cinema, cantine.
Consumption system: Combine with IC card readers, apply to super market, cantine, gym, subway, bus station.
Time attendance system: Combine with rfid/figerprint facial/veins readers, apply to factory, office, school, etc..
Construction system: Combine with CCTV/LED screens, apply to contruction site for safty.
ESD system: Combine with profession ESD tester for factory, special area entrance.
Optional features:
1) Sound and light alarm functions, including illegal intrusion alarm, anti-pinch alarm, etc.;
2) Counting function;
3) Infrared reset function;
4) The chassis is lengthened, the swing arm is lengthened, and so on.
Main structure and configuration
SUS304 standard case
Stainless steel swing arm
Turnstile control PCB
Direction indicator board
Power supply
Motor
Movement and transmission part 1 set
Infrared sensor 3 pairs
